LM2596 HVS High Voltage DC-DC Adjustable Step Down Buck Converter Module in Pakistan

LM2596 HVS High Voltage Buck Step DownLM2596HVS High Voltage Buck input voltage: 4.5-50V, the volume of L 40 * W 21.5 * H 13.5mm (including potentiometers). Input: IN input positive IN- input negative Output: OUT output positive OUT- output negative Adjustment method: first correct input power (between 4.5-50V) then multimeter to monitor the output voltage and adjust potentiometer (usually clockwise turn boost, buck turn counterclockwise), Output voltage: (3-35V) continuously adjustable (recommended load debugging). Minimum pressure: 1.5V Output current: rated current 2A, 3A maximum Output Power: 15W maximum Conversion efficiency: up to 92% (output voltage, the higher the efficiency) Static power consumption is only about 6mA. Connection: Welding, plus pin can be directly soldered after the PCB. Operating temperature: Industrial grade (-40 to 85 degrees Celsius) Load regulation: ± 1%LM2596 HVS High Voltage BuckLM2596HV module is a high input voltage version of the LM2596 Module. The LM2596HV module is a DC to DC converter buck converter module with an input voltage range of 4.5 volts to 50 volts and an output of 3 volts to 40 volts. This output is variable and can be varied using the on-board multi-turn potentiometer. Buck Converter Module is capable of driving a load up to 3A with high efficiency. When the output current required is greater than 2.5A(10W) an external heatsink is suggest.Input voltage: 4.5V-60VOutput Voltage(Less than input): 1.3V-30VOutput current: 3A maximumConversion efficiency: 92% (maximum)Switching frequency: 52KHzOutput ripple: 50mV (maximum) 20M-bandwidthLoad regulation: ± 0.5%Voltage regulation: ± 2.5%Operating temperature: -40 ℃ to 85 ℃en.wikipedia.org Categories: Converters, Dc-Dc Converters, Dc-Dc Step Down, Power Modules Tags: Buck, Buck Converter, High Voltage, LM2596 High Voltage, LM2596HVS, Step Down
